D3B Dozer Track Chain Assy Undercarriage Track Chain Smooth Finished

D3B Dozer Track Chain Assy Undercarriage Track Chain Smooth Finished
D3B Dozer Track Chain Assy Undercarriage Track Chain Smooth Finished D3B Dozer Track Chain Assy Undercarriage Track Chain Smooth Finished D3B Dozer Track Chain Assy Undercarriage Track Chain Smooth Finished D3B Dozer Track Chain Assy Undercarriage Track Chain Smooth Finished

Large Image :  D3B Dozer Track Chain Assy Undercarriage Track Chain Smooth Finished

Product Details:
Place of Origin: Fu Jian China
Brand Name: CCJT
Certification: ISO\CE
Model Number: D3B
Payment & Shipping Terms:
Minimum Order Quantity: 5PCS
Packaging Details: Standard Export Strong Paper Box, Wooden Pallet
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C
Supply Ability: 12000 sets/month
Contact Now Chat Now

D3B Dozer Track Chain Assy Undercarriage Track Chain Smooth Finished

Description
Other Brands: Excavator Track Link Package: Export Wooden Pallet
Material: High-strength Steel Surface Treatment: Heat Treatment
Color: Black Warranty: 1 Year
Finish: Smooth Colour: Yellow
Highlight:

D3B Dozer Track Chain

,

Undercarriage Track Chain Smooth Finished

,

Dozer Track Chain Smooth Finished

D3B Dozer Chain Track Link Excavator Track Link
Product Specifications
Attribute Value
Other Brands Excavator Track Link
Package Export wooden pallet
Material High-strength Steel
Surface Treatment Heat Treatment
Color Black/Yellow
Warranty 1 year
Finish Smooth
D3B Dozer Track Chain Assy Undercarriage Track Chain Smooth Finished 0
Product Overview
  • Compatible Model: Caterpillar D3B compact crawler bulldozer (or modified excavator versions of similar tonnage)
  • Track Type: Sealed & Lubricated (SALT) track chain, designed for medium-to-low load applications
  • Design Standard: Complies with Caterpillar TL (Track Link) series specification
Core Specifications
Dimensional Data
Parameter Value (mm/inches)
Pitch 152.4 mm (6")
Shoe Width 300 mm (12")
Link Thickness 45±2 mm
Bushing/Pin Diameter 38.1 mm (1.5")
Assembly Weight (per side) ~250 kg (varies by shoe type)
Material & Manufacturing
  • Track Links: Forged high-manganese steel (Mn18Cr2), quenched, hardness ≥HRC55
  • Pins & Bushings: Alloy steel (42CrMo), medium-frequency induction hardened, hardness HRC58-62
  • Sealing System: Nitrile rubber (NBR) seals + lithium-based grease for dust/water resistance
Configuration Options
Track Shoe Types
Type Application Features
Single-Grouser Hard terrain, rocky conditions High traction & wear resistance
Flat Shoes Turf/asphalt protection Minimizes ground disturbance
Wide Swamp Pads Mud/wet soils Extra width (400mm) to reduce sinking
Link Quantity
  • Standard for D3B: 39-41 links per side (varies by configuration)
Performance Features
  • Durability: Service life up to 4,000-6,000 hours (under normal conditions)
  • Maintenance Intervals: Grease replenishment every 500 hours, seal replacement at 2,000 hours
  • Compatibility: Interchangeable with similar models (e.g., D3C/D4B) after verifying pin dimensions
OEM & Aftermarket References
Caterpillar Part Numbers:
  • 8J-7111 (Complete link assembly)
  • 3J-7357 (Pin & bushing kit)
Key Selection Notes
  • Verify Machine Year: Early D3B models (pre-1980s) may use non-standard pitch (e.g., 5.5")
  • Match to Application: Opt for wide swamp pads in wet conditions to reduce lateral stress on links
  • Genuine Part Identification: Look for "CAT" logo and laser-etched part numbers on link sides
D3B Dozer Track Chain Assy Undercarriage Track Chain Smooth Finished 1
